300 mW UV-Silicon Photodiode Sensor with Ø10 mm Aperture
300 mW UV-Silicon Photodiode Sensor with Ø10 mm Aperture
The PD300R-UV silicon photodiode sensor is a wide spectral range circular geometry laser measurement sensor. It has a 10 mm aperture and a removable filter. Without filter, its spectral range is from 200 to 1100 nm and its optical power measuring range is from 20 pW to 3 mW. With filter the spectral range is 220 to 1100 nm and the power range is 2 µW to 300 mW.
- 200-1100 nm uv-silicon photodiode sensor with Ø10 mm aperture
- 20 pW to 300 mW power measurement range
- Includes removable filter
- Fiber optic adapters available See All Features
Features
Measuring Very Low Laser Powers with a Photodiode Sensor
In this short “Basics” video, we review in general the use of photodiode sensors for measuring very low laser powers.
Effects of Incidence Angle on Measurements
In this video, you will learn to what degree a beam’s incidence angle matters, and for which sensor types this should be taken into account.
