90° Phase Shift Beam Delivery Mirror, Copper, 80x60 mm, 20 mm Edge, Water-Cooled
Specifications
Type
90° Phase Shift Mirror
Optic Material
Copper
Coating Type
90PS-HR
Angle of Incidence
45°
Diameter
80 x 60 mm
Edge Thickness
20 mm
S1 Radius
Plano
S2 Radius
Plano
Absorption
<1.5%
Phase Shift Tolerance
90º±2º
Surface Quality
10-5 scratch-dig
Surface Irregularity
1 Fringe @ 633 nm
Power
2 Fringes @ 633 nm
Diameter Tolerance
+0/-0.12 mm
Thickness Tolerance
±0.25 mm
Wedge
<3' (arc minutes)
Water Cooled
Yes
