MMR-P coating is a cost-effective way to maximize reflection (>99.90% for S-Pol), improve performance, protect highly-sensitive mirror surfaces and prolong product life. OEM-approved MMR-P coating provides the highest total random reflection available with superior P reflection (>99.80%) and total random reflection (>99.85%) and is suitable for both Cu and Si mirrors. This coating is internal cavity radiation resistant and allows for a phase shift tolerance of ±2@45° and >70% reflection for 630-670nm, for superior cutting and cleaning capabilities.

Coating	Substrate	%R@45°@10.6	%S-Pol@45°@10.6	%P-Pol@45°@10.6	%R@45°@0.6328	PS@45°AOI
MMR	Si&Cu	99.8%	99.9%	99.75%	40%	0°±2°
MMR-A	Si&Cu	99.8%	99.85%	99.60%	40%	0°±2°
MMR-H	Si&Cu	99.7%	99.8%	99.60%	>80%@650±20nm	-
MMR-P	Si&Cu	-	99.9%	99.80%	≥55%@900-1000nm	0°±2°
